The FH6141 is an FMC-compatible interface module designed to convert one DisplayPort (DP) input and one DisplayPort output, compliant with the DP1.4 standard. Featuring 4-lane configuration, this module supports data rates up to 8.1Gbps per lane, delivering high-bandwidth video signal transmission for applications requiring ultra-high resolution and refresh rates.
Unit price
$ 556
The FH6141 is an FMC-compatible interface module designed to convert one DisplayPort (DP) input and one DisplayPort output, compliant with the DP1.4 standard. Featuring 4-lane configuration, this module supports data rates up to 8.1Gbps per lane, delivering high-bandwidth video signal transmission for applications requiring ultra-high resolution and refresh rates.
FH6141 has a standard FMC HPC interface that can be connected to the ALINX FPGA carrier board for use.
Click on the image to view a larger image.
Not all features are available simultaneously – please check the documentation for any applicable constraints.
All specifications are subject to change without notice. Please verify component specifications with vendor's datasheets.
ALINX provides product user manuals for each product.
| FMC Cards | 1 |
|---|
| Product Model | USD Price |
|---|---|
| FH6141 | 556 |
