AXRF47

AXRF47 dev Board & Kit with AMD Zynq™ US+ RFSoC XCZU47DR

The AXRF47 FPGA development board equipped with the AMD Zynq UltraScale+RFSoC series device, delivers standout performance with DDR4 SDRAM, QSPI Flash, Gigabit Ethernet, QSFP28, SFP, M2.

Unit price

$ 13182

Overview

AXRF47 dev Board & Kit with AMD Zynq™ US+ RFSoC XCZU47DR ZU47DR

Product Description

The AXRF47 development board Adopting Zynq UltraScale+RFSoC Gen3 series ZU47DR FPGA chip, integrating RF direct sampling data converter, FPGA logic, complete ARM processor subsystem, and high-speed transceiver. Supports 8-way 14bit RF-ADC with a maximum sampling rate of 5GSPS, and 8-way 14bit RF-DAC with a maximum sampling rate of 9.85GSPS. The RF input and output frequency response fully supports the frequency band below 6GHz. Provide a comprehensive RF signal chain, maximize input/output channel density, high bandwidth, heterogeneous processing capabilities, and low power consumption.


Meet the needs of large-scale MIMO radio, 5G baseband, fixed wireless access, cable TV access, testing and measurement, satellite communication, phased array radar/digital array radar, and other high-performance RF applications.

Applications



Key Features

Product Information

Development Board Features

Featuring the AMD/Xilinx's Zynq™ UltraScale+™ RFSoC ZU47DR-2FFVE1156I Adaptive SoC

Design-in Kit – The Fast Way to the Market, to get started with development straight out of the box.
The ALINX development board help shorten time-to-market for any AMD/Xilinx Zynq™ UltraScale+™ RFSoC based application.

AXRF47 dev Board & Kit with AMD Zynq™ US+ RFSoC XCZU47DR ZU47DR



* The AXRF47 development board consists of a ACRF47 SoM and base board. If you want to purchase ACRF47 SoM separately.
Please check the Relevant Products at the bottom of the page and click to learn more details.

What's Inside the Box

ALINX AMD Xilinx Zynq™ UltraScale+™ RFSoC ZU47DR development board and Some accessories

Heatsink Kit is an optimal cooling solution for ALINX FPGA and SoC modules – it is low-profile and covers the whole module surface.

System-on-Module1Base Board1
Heatsink Kit (preinstalled)112V power supply1
USB to Type-C cable1card reader1
TF card1


Product Selection Matrix

Product Matrix

Product ModelPreferred ModelFPGA DevicesDDR4 SDRAM (PS)DDR4 SDRAM (PL)QSPI FlashRF-ADCRF-DACGTY                     GTR                     USD Price
AXRF47ZU47DR-2FFVE1156I4 GB2 GB1 Gb88845283


1. For non-preferred models, a minimum order quantity (MOQ) may apply if the products are not in stock.
2. We offer custom configuration, a MOQ applies.
Please contact us for more details.


We offer complete documentations and a lot of demos and tutorials.
Please contact us should you have any need.
